Game of thrones brittle star
Tim O'Hara described this brittle-star discovered in the waters of New Caledonia. He named it the Game of Thrones Brittle Star, Ophiohamus georgemartini, because of its sharp thorns similar to those depicted on the Game of Thrones crown. Image: Caroline Harding
Tim O'Hara at the microscope
Tim takes time out from his duties as chief scientist on the Investigator voyage to indulge his passion for brittle-stars. Image: Asher Flatt

Blogging the abyss iconDay 32: Tim O'Hara, Museums Victoria

Why would you love a brittle-star? They have no eyes and no brain (just a ring of nerves). They almost always have a round central disc (with mouth, stomach and gonads), five radiating arms, some small spines on either side of the arms and maybe a few on the disc. They are known as 'brittle-stars' because early collectors found that they broke in pieces easily when dried. Not much going on really.

However, as a group they are amazingly successful. They have been around for more than 480 million years. All modern species date from a survivor of the great end-Permian extinction event of 252 million years ago, when most sea-life was obliterated. But now they cover almost every seafloor habitat, from the coast to the bottom of the deepest trenches, from the equator to the poles, and including rocky and muddy terrain. Now there are 2200 described species. But we are discovering with DNA that lots of these 'species' are actually groups of very similar animals, so it is likely that the final number will be more than 10 000 species.

Curly brittle stars
This cute and curly confection of brittle-stars surfaced towards the end of the RV Investigator voyage. Amphiophiura paraconcava was first described from a seamount in the Pacific Ocean.  Image: Asher Flatt

They mostly eat organic debris on the seafloor or hold up mucus covered arms to collect small animals in the water. Some are active carnivores and will pull down unfortunate shrimp or even small squid if they stray too near (see The Echinoblog). It is quite amazing to see them feeding in an aquarium. When not feeding, many species live hidden under rocks, only the tips of the arms emerging. These arm tips are covered in chemical and light sensors. Once food (such as tiny brine shrimps) is dropped into the aquarium, you see the arm tips rapidly stiffen in response. Slowly the animal emerges, sensing for danger. Then suddenly it becomes a free for all, the brittle-stars scurry over to the food, arms waving, rowing and pulling, until it is consumed.

Lupita Bribiesca-Contreras, Tim O'Hara and Di Bray
Lupita Bribiesca-Contreras, Tim O'Hara and Dianne Bray of Museums Victoria inspect brittle-stars caught on the Investigator. Lupita is a PhD candidate with the University of Melbourne and Museums Victoria, and is studying brittle-star evolution. Image: Asher Flatt

Apart from eating, the brittle-stars main concern is not being eaten. So in shallow sun-drenched waters often they have colourful patterns as a camouflage. Some can even change colour between night and day by expanding or contracting pigment cells in the skin. In deeper water they become orange or red, colours which appear black in low light marine waters. Others are a grey colour to match the seafloor mud. To further avoid being eaten, brittle-stars can emit a green or blue flashing light (see the blog post 'Beam us up Jérôme'). Some species will drop off a flashing arm when attacked: the fish grabs the arm and the rest of the animal escapes. Other species appear to use light to advertise their disgusting taste. Fish and crabs rapidly learn not to eat a flashing object!

Brittle-star ophiacantha
Brittle-star arms are useful for hunting, burrowing, feeding, providing light and sensing danger. Image: Robert Zugaro

Brittle-stars are related to the more familiar starfish, spiny sea urchins, sea cucumbers and feather stars, and all of these groups possess special organs called tube feet. On brittle stars, these tube feet are under the arm and are used like sticky fingers, catching small prey, burrowing into mud, or helping the animal move over rock. They are like long water-filled balloons that can be controlled by sucking in or pushing water in and out of the tube.

Brittle star montage
A selection of brittle-stars collected on the RV Investigator voyage. Images: Asher Flatt and Robert Zugaro

On this voyage we are discovering brittle-star paradise. There are lots of species down there in the abyss. From large white species that scoot across the mud, spiny orange ones that climb corals and sponges to get higher in the water for a better feed, to soft red ones that scavenge dead flesh. We pulled up a massive dead manta ray the other day from a seafloor 1000 metres below. It was over four metres across, and it was a stinking mess of cartilage, skin and flesh. It was covered in large sea hoppers (technically amphipods) and masses of bright red brittle-stars.

Manta ray in beam trawl
Extracting the massive manta ray carcass from the trawl net. The decomposing manta provided a bonanza for hungry red brittle-stars, Ophiura flagellata. Image: Asher Flatt (Inset: Karen Gowlett-Holmes)

So to answer my original question. I like brittle-stars. I have liked them ever since my year 10 biology teacher pointed them out to me. I haven’t always researched brittle-stars, but I keep on coming back to them. Since they are everywhere across the seafloor, they are great to map (see my previous blog post). For me they are a fine example of marine evolution. If we can understand how and where these guys evolved, maybe we can begin to grasp how life has originated and flourished on our blue planet.

bioluminescent brittle-star
A fluorescing brittle-star, one of many bioluminescent deep-sea animals photographed on the RV Investigator voyage by Belgian scientist Jerome Mallefet.
Tim O'Hara on deck
It's back to chief scientist duties: Tim contemplates the Brenke sled which has returned to the deck from sampling in the Coral Sea, minus the lever that opens its nets. At least the damage occurred towards the end of the voyage. Image: Robert Zugaro
